The MAXGO GCH080 180 degree square glass bracket connects two fixed shower panels in a straight line. Its square profile creates a simple, aligned junction between adjacent glass panels.
Choose the 180° configuration for an inline glass layout. The paired plates hold the adjoining panels on either side of the joint; confirm the panel spacing and fixing locations during enclosure planning.
GCH080 features and specifications
- Material: Solid brass
- Connection: 180° glass to glass
- Profile: Square
- Glass: Monolithic tempered glass, 8–12 mm (5/16"–1/2")
- Glass preparation: Round holes to the matching connection drawing
Glass preparation and installation
Use the 180° glass-to-glass dimension and glass drilling drawing in the gallery. Confirm hole positions and edge distances against the actual bracket before ordering the glass. Complete all glass cutting and drilling before tempering. Fit gaskets appropriate for the glass thickness and keep metal surfaces clear of the glass.
Align the panels at the specified connection angle before securing the bracket. Determine bracket quantity and positions for the individual enclosure.
Finishes and ordering
Available finishes are Polished Chrome, Brushed Nickel, Polished Nickel, Matte Black and Satin Brass. Specify GCH080, the finish, glass thickness and quantity when requesting a quotation.
Related models
For an inline connection with beveled plates, compare GCH280. Browse the shower glass bracket range for other connection angles and profiles.
