SHS280 180° Glass-to-Glass Shower Door Hinge
The SHS280 is a standard-duty 180° glass-to-glass shower door hinge with a round-corner design. It connects a moving shower door to a fixed glass panel in a straight 180° glass configuration.
The rounded profile gives SHS280 a softer exterior appearance while retaining the same 180° glass-to-glass installation concept as the square-corner SHS080.
Round Corner Design
SHS280 is intended for projects where a rounded hinge profile is preferred over a straight-edged square-corner design.
The difference from SHS080 is primarily the external corner profile rather than the hinge function.
For the same 180° glass-to-glass configuration with a square-corner body, see the SHS080 180° Glass-to-Glass Shower Door Hinge.
Self-Centering Action
The hinge self-centers as the door returns to within approximately 15° of the closed position.
A reversible 5° pivot pin is also available where a different resting position is required.
Product Specifications
- Model: SHS280
- Application: Glass-to-Glass
- Mounting Angle: 180°
- Corner Style: Round Corner
- Duty: Standard Duty
- Material: Forged Solid Brass
- Glass Thickness: 8–12 mm Tempered Glass
- Size: 3.54″ W × 2.17″ H
- Self-Centering: Within 15° of closed position
- Optional Pivot Pin: Reversible 5°
- Screw Cover: Optional snap-on cover
- Load Reference: 2 hinges / 99 lb (45 kg); 3 hinges / 132 lb (60 kg)
- Cycle Test: At least 100,000 opening and closing cycles
- Finishes: Polished Chrome, Brushed Nickel, Matte Black, Satin Brass
Selecting SHS280
SHS280 is suitable when a frameless shower enclosure requires a 180° glass-to-glass hinge with a round-corner design.
Prefer a straight-edged profile? See the SHS080 180° Glass-to-Glass Shower Door Hinge – Square Corner.
